Topping MX3s

Name: Topping MX3s
Brand: Topping
SKU: MX3s-B
Price: 239.0 EUR
Availability: InStock

Amplifier/DAC 2 x 50W and aptX

€239,00 €239,00

Alex

960 457 885

Bluetooth aptX Adaptative Amplifier/DAC

Details

MX3s Topping, the most precise dynamics

The MX3s features an AKM DAC and is equipped with a Qualcomm Bluetooth chip, the QCC3040, providing exceptional USB, optical, coaxial and Bluetooth input capabilities. This allows for easy connection of various audio sources, such as computers, set-top boxes, DVD players, smartphones and tablets, making it incredibly versatile.

Efficient class D amplifier

It can output 62W x2 at 10% distortion and 50W x2 at 1% distortion under 4-Ohm load, 40W x2 at 10% distortion and 30W x2 at 1% distortion under 8-ohm load. The MX3s is suitable for daily use.

The selectable two step gain settings for power amplifier and headphone amplifier adapts to different audio source. The gain can be set on the remote control.

Bluetooth Connectivity

The MX3s supports Bluetooth protocols such as AAC, SBC, aptX, aptX-HD, aptX Adaptive, achieving transmission distortion below 0.001%. It brings you an exceptional audio experience.

Subwoofer output and signal detection

The MX3s has a built-in subwoofer output that can be wired for a full 2.1-channel premium listening experience.

The digital input of the MX3s supports and automatic power on/off function, which turns the power on immediately when a valid digital signal is detected. If a valid signal is lost, it will automatically turn off (goes into standby) within 1 minute.

Built-in equaliser? Of course it is

With the MX3s, you can adjust the treble and bass youeself from the range -10dB to +10dB.

The M3Xs screen can be set to automatically turn off after 30 seconds without operatiom, and only the current input is displayed when te screen is off.

MX3s can set to display the volume in percentage or in dB.

What's in the box?

1 x Topping MX3S
1 x Power adaptor
1 x Power cable
1 x Cable USB
1 x Remote control
1 x Bluetooth Antenna

Do you have questions about this or other products in our catalogue? Contact us

Specifications

Technical specifications

Product Type: Amplifier/DAC
Inputs
- Bluetooth
- 1 x stereo RCA
- 1 x Coaxial
- 1 x Optical Toslink
- 1 x USB-C
Outputs:
- Stereo speaker output
- 1 x RCA mono subwoofer output
- 1 x 3.5mm jack headphone output
Supported rates: PCM up to 24 bit-192 kHz
Bluetooth codecs: AAC, SBC, aptX, aptX-HD, aptX adaptive
Power supply voltage: 26VDC (power supply included))
Dimensions: 120 x 165 x 40 mm

USB / Optical / Coaxial headphone amplifier specifications

THD+N @ 1kHz (peso A): < 0,003 % a 270 mW, 32 Ω / < 0,001 % a 30 mW, 300 Ω
SNR at max output, 1 kHz (A-wt): 115dB
Dynamic Range @ 1kHz (A-wt): 115dB
Frequency Response: 20 Hz-20 kHz (+0,1 dB/-0,3 dB) / 20 Hz-40 kHz (+0,1 dB/-1,0 dB)
Output Level: 3,4 Vpp @ G=L / 15,6 Vpp @ G=H
Noise (A-Weight): < 2,0 µVrms @ G=L / < 7,0 µVrms @ G=H
Crosstalk@1kHz: -90dB
Sensitivity: 0dBFS @ G=L / 0dBFs @ G=H
Gain: 2dB (Vrms/FS) @ G=L / 14.8dB (Vrms/FS) @ G=H
Impedance: <0,5 Ω
Output power: 2*700 mW a 32 Ω, THD+N < 1 % / 2*400 mW a 62 Ω, THD+N < 1 % / 2*100 mW a 300 Ω, THD+N < 1 %
Load impedance: > 8Ω

AUX headphone amplifier specifications

SNR at max output, 1 kHz (A-wt): 127dB
Dynamic Range @ 1kHz (A-wt): 127dB
Frequency Response: 20 Hz-20 kHz (+0,1 dB/-0,3 dB) / 20 Hz-40 kHz (+0,1 dB/-1,0 dB)
Output level: 3,4 Vpp @ G=L / 15, Vpp @ G=H,
Noise (A-Weight): < 2,0 µVrms @ G=L / < 7,0 µVrms @ G=H
Crosstalk@1kHz: -90dB
Sensitivity: 4,2 Vrms @ G=L / 1,2 Vrms @ G=H
Gain: -0.2dB @ G=L / 12.6dB @ G=H
Impedance: <0,5 Ω
Output power: 2*700 mW a 32 Ω, THD+N < 1 % / 2*400 mW a 62 Ω, THD+N < 1 % / 2*100 mW a 300 Ω, THD+N < 1 %
Load impedance: > 8Ω

Bluetooth specifications

THD+N @ 1kHz (peso A): < 0,003 % a 270 mW, 32 Ω / < 0,001 % a 30 mW, 300 Ω
SNR a max out, 1 kHz (A-wt): 115dB
Dynamic Range @ 1kHz (A-wt): 115dB
Frequency Response: 20Hz-20kHz (+0dB/-2dB)
Gain level: 3,4 Vpp @ G=L / 15,6 Vpp @ G=H
Noise (A-Weight): < 2,0 µVrms @ G=L / < 7,0 µVrms @ G=H
Crosstalk@1kHz: -90dB
Sensitivity: 0dBFS @ G=L / 0dBFs @ G=H
Gain: 2dB (Vrms/FS) @ G=L / 14.8dB (Vrms/FS) @ G=H
Output impedance: <0,5 Ω
Output power: 2*700 mW a 32 Ω, THD+N < 1 % / 2*400 mW a 62 Ω, THD+N < 1 % / 2*100 mW a 300 Ω, THD+N < 1 %
Load impedance: > 8Ω

USB/Optical/Coaxial amplifier specifications

THD+N @ 1kHz (Weight A): < 0,005 % a 5 W, 4 Ω / < 0,004 % a 5 mW, 8 Ω
SNR @ max out, 1kHz (A-wt): 110dB
Dynamic Range @ 1kHz (A-wt): 110dB
Frequency Response: 20 Hz-20 kHz (+0,1 dB/-0,-dB) / 20 Hz-40 kHz (+0,1 dB/-1,5 dB)
Output Level: 40Vpp @ 4Ω / 44Vpp @ 8Ω
Noise (A-weight): < 60 µVrms @ G=L / < 100 µVrms @ G=H
Crosstalk @ 1kHz: -90dB
Sensitivity: -2.0dBFS @ G=L / -8.0dBFs @ G=H
Gain: 26,5 dB (Vrms/FS) @ G=L / 32,5 dB (Vrms/FS) @ G=H
Output impedance: < 0,2 Ω
Output power: 2*62W @ 4Ω, THD+N < 10%, 2*50mW @ 4Ω, THD+N < 1%, 2*40W @ 8Ω, THD+N < 10%, 2*30W @ 8Ω, THD+N < 1%
Load impedance: 4-8Ω
